Maximum pressure: 500 bar / Water flow rate: 35 L/min / Engine power: 37.5 kw
Cold water unit with trailer 500bar – 2.100L/h
Description
Cold water unit with trailer JTR-H
Self-contained cold water pressure washer with trailer
Great versatility and manageability
High pressure jetting unit on trailer for hydroscarification, hydrodemolition, industrial and nautical maintenance. – Manual supply hose reel with 50 mt 3/4 ” hose. – The water tank capacity is 600 L , in fiberglass. – Fuel tank of 75 L. – Single axle steel trailer with European homologation for road circulation. – High quality parking brake and stabilizing jacks. – Towing eye for 50 mm diameter. – Fiberglass deck. – Automatic throttle control. – Pressure gauge, manual pressure regulator, safety valve.
Image gallery
Not sure which product to choose?
Consult our technicians, who will advise you on the most suitable model for you. Our products have 2 years warranty and are EU approved. In addition, we have a specialized after-sales department to meet any need. By choosing a product, you are buying years of peace of mind, efficiency and productivity for your business. For prices and purchase details, please contact us. Find out where you can buy a product. We have distributors and stores in: Barcelona, Madrid, Seville, Valencia, Vizcaya, Galicia, Aragon, Navarra, Alava, among others.
Self-contained cold water pressure washer with trailer
Technical data
Features
Features
| TECHNICAL FEATURES | JTR-H 30/500 |
|---|---|
 |
|
| Code | JTRH-500 |
| Maximum pressure | 500 bar |
| Working pressure | 480 bar |
| Water flow rate | 2.100 L/h |
| Hydrodynamic power | 17,500 L/min x bar |
| Injector | 1/4″15º 070 |
| Revolutions | 1,450 rpm. |
| Power supply | Diesel |
| Engine | Kohler LDW 2204 |
| Engine power | 50 HP |
| TSS – Automatic shutdown device | No |
| Max. inlet temperature | 55º C |
| Detergent tank | No |
| High pressure pipe length | 50 m |
| Dimensions | 3,300 x 1,600 x 1,530 mm (3,300 x 1,600 x 1,530 mm) |
| Net weight | 950kg |
